DISPLAY AIO 21.5" MV215FHM-N40

Size: 21.5 inch

Number of dots: 1920(RGB)×1080, FHD, 16:9

Signal Type: LVDS (2 ch, 8-bit), 30 pins Connector

Refresh Rate: 75Hz

Model No.: MV215FHM-N40

Touchscreen: Without

Manufacturer Screen: BOE

Active Area: 476.064×267.786 mm (H×V)

Weight: 1.83Kgs (Typ.)

Luminance: 250 cd/m² (Typ.)

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10)

Good View at: Symmetry

Dispaly Colors: 16.7M, 73% NTSC

Total Power: 12.41/16.2W (Typ./Max.)

Voltage Supply 5.0V (Typ.)

Max. Ratings Storage Temp. -20 ~ 60 °C   Operating Temp. 0 ~ 50 °C

Screen Type: a-Si TFT-LCD, LCM

Dot Layout: RGB Vertical Stripe

Outline Area: 484.5×284.4×13.2 mm (H×V×D)

Surface Feature: Antiglare, Hard coating (3H)

Contrast Ratio: 1000 : 1 (Typ.) (TM)

Display Type:ADS, Normally Black, Transmissive

Response (ms): 14 (Typ.)(G to G)

Backlight: 17S4P WLED, 30K hrs, No Driver
